How to prepare a trichogram with transparent enamel base coat?

Submitted on: 18/04/2021
Approved on: 20/06/2021

Financial support: None
Conflict of interest: None
How to cite this article: Rezende HD, Santos BO, Elias BM, Dinato SLM, Dias MFRG, Trüeb RM. How to prepare a trichogram with transparent enamel base coat? Surg Cosmet Dermatol. 2021;13:20210037.

Abstract

The trichogram is an easy and semi-invasive method, useful for evaluating different types of hair loss in daily practice. To date, there is no standardized methodology on how to collect and perform the exam. The use of a liquid interface between the slide and the coverslip to read the trichogram under optical microscopy varies widely in the literature. Among the alternatives, transparent enamel base coat is an inexpensive, accessible, and practical option, providing the examiner with proper visualization of the hair shafts with minimal air bubbles formation.

Keywords: Alopecia; Hair diseases; Scalp dermatoses

INTRODUCTION

The recent expansion of knowledge in trichology challenges the physician in searching for a more detailed and objective medical evaluation. However, cutting-edge technologies for the assessment of hair and scalp are not always available. In this context, the trichogram is a semi-invasive method with easy application and low cost, accessible to every dermatologist dedicated to studying hair disorders.

DISCUSSION

After Trotter (1989-1991) described the hair growth cycle, most studies on follicular dynamics were conducted based on the microscopic evaluation of hairy roots (HR).¹ The technique for this assessment, later called trichogram, still helps to interpret various disorders of the hair growth cycle and has practical value since it is a semi-invasive method with easy applicability and low cost.^1,2,3

The exam consists of collecting 50 to 100 hair strands, usually from two scalp regions (parietal and occipital), and subsequently adjusting the hairy roots on a glass slide.^1,4 A coverslip is generally superimposed on the hair shaft to facilitate reading under an optical microscope, using a liquid medium to fix the hair strands when conducting the evaluation is recommended.

To date, no standardization defines the best way to fix the hair shafts for reading under the microscope. A review of 76 articles indexed in PubMed with the keywords “trichogram” and “technique” published from 1970 to 2021 showed that only 14 studies (18.4%) mentioned some liquid or other fixation midia when conducting the technique. Of these, one used formaldehyde (7.15%),⁵ two used a drop of Canadian balsam (14.28%),^6,7 three used only a thin glass slide cover (21.42%),^8,9,10 two used double-sided tape (14.28%),^4,11 five used adhesive tape (37.71%),^{2,12,13,14,15} one used unspecified liquid (7.15%),¹⁶ and 62 (81.57%) did not mention or did not use any form of fixation of the hair strands.

A mixture of 45% acrylic resin and 55% xylenes (Eukitt^®) can be used for fixing and reading the trichogram with excellent results (Figure 1A). It provides little formation of air bubbles (artifact) and facilitates exam interpretation, especially for inexperienced examiners. On the other hand, this technique is a more expensive option, and it’s more challenging to be found in some parts of Brazil. In turn, the use of liquids that do not promote adherence of the hair strands to the glass slide – such as formaldehyde, 0.9% saline solution, and distilled water - facilitate the movement of hair strands on the slide, making it difficult to visually analyze and count the hairy roots in different optical fields.

In the authors’ experience, using a transparent enamel base coat is a cheap, easy-to-access, and helpful strategy when preparing the hair shafts for the trichogram. However, we haven’t found it in the literature among the various options. When opting for this strategy, the examiner must place the hair strands on a previously prepared slide with a generous amount of enamel base coat and then cover with a coverslip glass slide (Figures 2A - 2D). Drying is quick, and fixation is adequate, with minimal air bubbles formation (artifact) (Figure 1B). Also, the material can be kept for analysis on subsequent days.

CONCLUSION

Trichograms can be performed with or without liquid media, and to date, there is no standardization. However, using a colorless enamel base coat in exam preparation is a good practical option. It allows excellent fixation of the hair strands in the slide/coverslip interface, generates few air bubbles, and has fast drying and low-cost wide range availability nationwide.

AUTHORS' CONTRIBUTION:

Hudson Dutra Rezende 0000-0002-7039-790X
Statistical analysis; approval of the final version of the manuscript; study design and planning; preparation and writing of the manuscript; data collection, analysis, and interpretation; active participation in research orientation; intellectual participation in propaedeutic and/or therapeutic conduct of studied cases; critical literature review; critical revision of the manuscript.

Bruna Orquiza dos Santos 0000-0002-1983-3868
Approval of the final version of the manuscript; study design and planning; data collection, analysis, and interpretation; active participation in research orientation; intellectual participation in propaedeutic and/or therapeutic conduct of studied cases; critical literature review.

Bruna Margatho Elias 0000-0003-2615-5775
Statistical analysis; approval of the final version of the manuscript; preparation and writing of the manuscript; data collection, analysis, and interpretation; active participation in research orientation; intellectual participation in propaedeutic and/or therapeutic conduct of studied cases; critical literature review; critical revision of the manuscript.

Sandra Lopes Mattos Dinato 0000-0002-4547-0474
Statistical analysis; approval of the final version of the manuscript; study design and planning; preparation and writing of the manuscript; data collection, analysis, and interpretation; active participation in research orientation; intellectual participation in propaedeutic and/or therapeutic conduct of studied cases; critical literature review; critical revision of the manuscript.

Maria Fernanda Reis Gavazzoni Dias 0000-0001-7397-7478
Statistical analysis; approval of the final version of the manuscript; study design and planning; preparation and writing of the manuscript; data collection, analysis, and interpretation; active participation in research orientation; intellectual participation in propaedeutic and/or therapeutic conduct of studied cases; critical literature review; critical revision of the manuscript.

Ralph Michel Trüeb 0000-0003-4970-0350
Statistical analysis; approval of the final version of the manuscript; study design and planning; preparation and writing of the manuscript; data collection, analysis, and interpretation; active participation in research orientation; intellectual participation in propaedeutic and/or therapeutic conduct of studied cases; critical literature review; critical revision of the manuscript.

REFERENCES:

1. Ralph M, Trüeb. The difficult hair loss patient: guide to successful management of alopecia and related conditions. New York: Springer; 2015.

2. Dhurat R, Saraogi P. Hair evaluation methods: merits and demerits. Int J Trichology. 2009;1(2):108-19.

3. Serrano-Falcón C, Fernández-Pugnaire MA, Serrano-Ortega S. Evaluación del pelo y cuero cabelludo: tricograma. Actas Dermosifiliogr. 2013;104(10):867–76.

4. Piérard GE, Piérard-Franchimont C, Marks R, Elsner P; EEMCO group (European Expert Group on Efficacy Measurement of Cosmetics and other Topical Products). EEMCO guidance for the assessment of hair shedding and alopecia. Skin Pharmacol Physiol. 2004;17(2):98-110.

5. Chapman DM, Miller RA. An objective measurement of the anchoring strength of anagen hair in an adult with the loose anagen hair syndrome. J Cutan Pathol. 1996;23(3):288-92.

6. Astore IP, Pecoraro V, Pecoraro EG. The normal trichogram of pubic hair. Br J Dermatol. 1979;101(4):441-5.

7. Barman JM, Astore I, Pecoraro V. The normal trichogram of the adult. J Invest Dermatol. 1965;44:233-6.

8. Sánchez P, Serrano-Falcón C, Torres JM, Serrano S, Ortega E. 5α-Reductase isozymes and aromatase mRNA levels in plucked hair from young women with female pattern hair loss. Arch Dermatol Res. 2018;310(1):77-83.

9. Kunz M, Seifert B, Trüeb RM. Seasonality of hair shedding in healthy women complaining of hair loss. Dermatology. 2009;219(2):105-10.

10. Galliker NA, Trüeb RM. Value of trichoscopy versus trichogram for diagnosis of female androgenetic alopecia. Int J Trichology. 2012;4(1):19-22.

11. Rushton H, James KC, Mortimer CH. The unit area trichogram in the assessment of androgen-dependent alopecia. Br J Dermatol. 1983;109(4):429-37.

12. Rasheed H, Mahgoub D, Hegazy R, El-Komy M, Abdel Hay R, Hamid MA, Hamdy E. Serum ferritin and vitamin d in female hair loss: do they play a role? Skin Pharmacol Physiol. 2013;26(2):101-7.

13. Dhurat R, Chitallia J, May TW, Jayaraaman AM, Madhukara J, Anandan S, et al. An Open-Label Randomized Multicenter Study Assessing the Noninferiority of a Caffeine-Based Topical Liquid 0.2% versus Minoxidil 5% Solution in Male Androgenetic Alopecia. Skin Pharmacol Physiol. 2017;30(6):298-305.

14. Yavuz IH, Yavuz GO, Bilgili SG, Demir H, Demir C. Assessment of heavy metal and trace element levels in patients with telogen effluvium. Indian J Dermatol. 2018;63(3):246-50.

15. Serrano-Falcón C, Fernández-Pugnaire MA, Serrano-Ortega S. Hair and scalp evaluation: the trichogram. Actas Dermosifiliogr. 2013;104(10):867-76.

16. Hillmann K, Blume-Peytavi U. Diagnosis of hair disorders. Semin Cutan Med Surg. 2009;28(1):33-8.
